Wall mount, double section Lanberg cabinet WF02-6612-10S is a solution designed to expand networks, installation of cabling and flexible equipment montage in 19" with max. 60kg. loading capacity. It can be used in networks, server rooms, small, medium businesses. It can also work in low voltage systems such as cable television networks, alarm systems, fire protection systems and access control systems, CCTV and IP surveillance. Construction is made of high grade cold rolled steel which characterized by excellent design and high quality of craftsmanship. By additional section, you can easily lead fittings in the rear, perform maintenance contained equipment or upgrade by installing new devices. Cabinet is equipped with front temper glass door with lock and possibility installing on right or left side. The equipment also allows installation on both sides of the rear section, which are supplied with the lock. It has removable side panels (include locks). You can put the wiring through entry cable on top and bottom panels (with blank entry panels). Cabinet structure for self-assembly is in three flat packs which facilitates transport. In addition, parcel includes additional accessories for rails mounts, M6 cage nuts and blank entry panels.

- Manufactuer: Lanberg,
- Manufactuer code: WF02-6612-10S,
- Cabinet type: Wall mount,
- Body color: Grey RAL7035,
- Height: 12U,
- Cabinet dimensions (W x D x H): 600x600x635 mm,
- Packaging dimensions (W x D x H): 62x65x32.5 cm,
- Spacing between rack rails: 450 mm,
- Spacing between holes in rack rails: 475 mm,
- Internal spacing between rack rails: 500 mm,
- Loading capacity: max. 60 KG,
- Degree of protection: IP20,
- Doors type: Temper glass,
- Standard: ANSI/EIA RS-310-D, IEC297-2, DIN41494; PART1 & PART7, ETSI,
- Material: High grade cold rolled steel, powder coated,
- Fan avaliable: Yes, 120mm, 110V or 220V,
- Glass thickness: 5.0 mm,
- Sheet thickness: vertical mounting rails - 1,50 mm; mounting profile - 1,50 mm; others - 1,20 mm; top & bottom & side panel - 1,00 mm,
- Cable entry panel: Top, Bottom,
- Included: Accessory bag, earth kit, front and rear door lock, two side panels with locks, 10 cage nuts M6.
